Specifications

• Engine

  add remove
  • Engine Type:
    Single-Cylinder
  • Engine:
    Standard
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    4
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    OHV
  • Bore (mm):
    96
  • Bore (in):
    3.78
  • Stroke (mm):
    71.5
  • Stroke (in):
    2.81
  • Displacement (cc):
    518
  • Displacement (ci):
    31.6
  • Starter:
    Electric
  • Fuel Type:
    Gas
  • Fuel Requirements:
    Regular
  • Carburetion:
    Standard
  • Fuel Injector:
    Yes
  • Fuel Injector Size (mm):
    36
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Parental Controls:
    Not Available
  • Snorkel Air Intake:
    Not Available
  • Engine Block Heater:
    Not Available
  • Speed Governor:
    No
  • Other Engine:
    Not Available
  • Compression Ratio:
    9.5:1
• TRANSMISSION

  add remove
  • Transmission:
    Standard
  • Transmission Type:
    Manual / Automatic Clutch
  • Number Of Speeds:
    5
  • Hi / Low Range:
    Yes
  • Primary Drive (Rear Wheel):
    Shaft
  • Primary Drive (Front Wheel):
    Shaft
  • Reverse:
    Yes
  • Adjustable Throttle:
    Not Available
  • Other Transmission:
    Not Available
• DRIVE LINE

  add remove
  • Driveline:
    Standard
  • Driveline Type:
    Selectable 4X2 / 4X4
  • Number Of Driveline Modes:
    2
  • Rear Solid Axle:
    No
  • Limited Slip Differential:
    Not Available
  • Differential Lock:
    Standard
  • Differential Lock Location:
    Rear
  • Driveline Brand:
    TraxLok™
  • Other Drive Line:
    Not Available
• TECHNICAL SPECIFICATIONS

  add remove
  • Dimensions:
    Standard
  • Length (mm):
    2667
  • Width (in):
    50
  • Width (mm):
    1270
  • Height (in):
    71.2
  • Height (mm):
    1808.5
  • Wheelbase (in):
    73
  • Wheelbase (mm):
    1854.2
  • Turning Radius (ft):
    12.8
  • Ground Clearance (in):
    8.5
  • Ground Clearance (mm):
    215.9
  • Weight:
    Standard
  • Towing Capacity (lbs):
    1000
  • Towing Capacity (kgs):
    453.6
  • Capacities:
    Standard
  • Fuel Capacity (gal):
    4.1
  • Fuel Capacity (l):
    15.5
  • Fuel Capacity Reserve (gal):
    1.1
  • Fuel Capacity Reserve (l):
    4.2
  • Performance:
    Standard
  • Wet Weight (lbs):
    1060
  • Wet Weight (kg):
    481
• SUSPENSION

  add remove
  • Front Suspension:
    Standard
  • Front Suspension Type:
    Independent Double Wishbone
  • Front Travel (in):
    5.8
  • Front Travel (mm):
    147.3
  • Rear Suspension:
    Standard
  • Rear Suspension Type:
    Independent Double Wishbone
  • Rear Suspension Material:
    Steel
  • Rear Travel (in):
    5.9
  • Rear Travel (mm):
    149.9
  • Number Rear Shock Absorbers:
    2
  • Rear Stabilizer Bar:
    Yes
  • Air Adjustable:
    No
  • Center Suspension:
    Not Available
  • Front Adjustable Fork Pre-Load:
    No
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Other Suspension:
    Not Available
• WHEELS & TIRES

  add remove
  • Wheels:
    Standard
  • Wheels Composition:
    Steel
  • Front Tire Diameter (in):
    24
  • Rear Tire Diameter (in):
    24
  • Wheel Weights:
    Not Available
  • Tires:
    Standard
  • Front Tire Width:
    8
  • Front Wheel Diameter:
    12
  • Rear Tire Width:
    10
  • Rear Wheel Diameter:
    12
  • Front Tire (Full Spec):
    Maxxis® 24 x 8-12
  • Rear Tire (Full Spec):
    Maxxis® 24 x 10-12
  • Tire Chains:
    Not Available
  • Spare Tire:
    Not Available
  • Tire Brand:
    Maxxis®
  • Other Wheels & Tires:
    Not Available
• BRAKES

  add remove
  • Brakes:
    Standard
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    7.9
  • Front Brake Diameter (mm):
    200
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    6.7
  • Rear Brake Diameter (mm):
    170
  • Anti-Lock Brakes:
    Not Available
  • Parking Brake:
    Standard
  • Engine Braking:
    Standard
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
  • Linked Brake System Front to Rear:
    Not Available
  • Other Brakes:
    Not Available
