Specifications

• Engine & Drivetrain

  add remove
  • Engine Type:
    In-Line
  • Cylinders:
    4
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    16
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    2.64
  • Stroke (in):
    1.81
  • Displacement (cc):
    649
  • Carburetion Type:
    Fuel Injected
  • Turbocharged:
    No
  • Supercharged:
    No
  • Compression Ratio:
    11.6:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
  • Gear Ratio (1):
    3.07
  • Gear Ratio (2):
    2.35
  • Gear Ratio (3):
    1.89
  • Gear Ratio (4):
    1.56
  • Gear Ratio (5):
    1.37
  • Gear Ratio (6):
    1.21
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    57
  • Fuel Capacity (gal):
    4.1
  • Fuel Capacity Reserve (gal):
    0.8
  • Length (in):
    83.8
  • Width (in):
    29.5
  • Height (in):
    45.1
  • Ground Clearance (in):
    5.1
  • Wet Weight (lbs):
    466
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Suspension Size (in):
    1.6
  • Front Travel (in):
    4.7
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Suspension Material:
    Aluminum
  • Rear Travel (in):
    5.1
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    1
  • Air Adjustable:
    No
  • Front Suspension Brand Name:
    Showa®
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Chromed:
    No
  • Front Tire (Full Spec):
    Dunlop® Sportmax 214F: 120/70ZR 17 58W
  • Rear Tire (Full Spec):
    Dunlop® Sportmax 214: 180/55ZR 17 73W
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    12.2
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    9.4
  • Anti-Lock Brakes:
    Standard
  • Linked Brake System Front to Rear:
    Standard
  • Brake Brand Name:
    Nissin
