Honda Generator Electric Start 6500

Honda Generator Electric Start 6500

Description :

The Electric Start 6500 has premium features for demanding commercial usage (non-GFCI applications) and reliable home backup use.

  • Portable power with premium features and traditional Honda durability and performance
  • Powerful, easy-start Honda iGX390 commercial-grade engine
  • 12 VDC battery charging capability with optional charge cable
  • Cold Climate TechnologyTM aids continuous running in cold weather conditions
  • Voltage Selector Switch allows both 120 V and 240 V output, or total generator output to be available through any of the 120 volt outlets, limited only by the capacity of the individual outlet for powering devices with larger wattage requirements.
  • 6,500 watts maximum AC output
  • Auto-throttle further extends running time by automatically adjusting engine speed to idle when under no load
  • Standard wheel kit with positive lock folding handles for easy transportation and convenient, compact storage
  • Honda exclusive iAVR (Intelligent Auto Voltage Regulation) system for stable power delivery and available extra wattage (7,000 watts for 10 seconds to start larger equipment)

Specification

Generator Type: Brush type
Maximum AC Output (Watts): 6,500
AC Voltage Available: 120 / 240
Maximum Continuous AC Output (Watts): 5,500 7,000 (iAVR)
Max. Rated AC Amperage @ 120 V / 240 V: 45.8 / 22.9 (58.3 / 29.2 for 10 sec. iAVR)
Frequency (Hertz): 60
Automatic Voltage Regulator: Standard iAVR (Intelligent Automatic Voltage Regulator)
DC Output Volts / Amps: 12 / 8
Common Duplex Receptacle Specifications: 40 amps/120 VAC continuous is available as combined total from these twin duplex AC receptacles. Maximum of 20 amps available from each GFCI duplex receptacle.
DC Receptacle Specifications: 8 amps/12 VDC is available from these +/- thumb screw terminals. Important Note: AC and DC output can be used simultaneously on this series only. DC system uses floating N (Neutral) type.
DC Charging Cable: Optional (P/N 32650-825-015)
High Capacity 120 / 240 VAC Twist Lock Receptacle Specifications: This receptacle (NEMA # L5-30R) will supply 30 amps at 120 VAC continuously. This receptacle (NEMA # L14-30R) will supply 22.9 amps (5.5 kVA) at 240 VAC continuously.
Engine Type: Honda iGX390T2 OHV, 4-stroke, air-cooled
Displacement: 389 cc
Starting System: Electric/recoil
Low Level Oil Alert System: Standard
Auto Throttle: Standard
Remote Start Capability: Optional
Fuel Tank Capacity: 23.5 litres (5.17 Imp. gal.)
Transport Wheels: 2 Wheel standard
Lifting Hook: Optional (P/N 06810-Z22- A30ZA)
Battery: Standard (P/N 31500-MCR-J01)
Approximate Running Time (hrs.) / Tankful: 6.9** / 10.4****
Rated Fuel Consumption (litres/hr): 3.40**
Noise Level dB(A) (1.5 m to 7 m): 73**
Length (Without Handles and Wheels): 681 mm (26.8 in.)
Length (With Handles and Wheels): 1,051 mm (41.4 in.)
Width (Without Handles and Wheels): 530 mm (20.9 in.)
Width (With Handles and Wheels): 706 mm (27.8 in.)
Height (Without Lift-Hook): 719 mm (28.3 in.)
Height (With Lift-Hook): 773 mm (30.4 in.) optional lift hook
Dry Weight: 104.8 kg (231 lbs.)
Cold Climate Technology: Standard
